Lowered C6 Corvette with Borla Exhaust and Cray Wheels


Overview
Model: Chevrolet Corvette Coupe.
Body style: 2-door hatchback coupe with removable roof.
Driveline: Rear-wheel drive
Construction: Composite body panels, Hydro-formed steel frame with aluminum and magnesium structural and chassis components

ModificationsExhaust: Borla S-Type Rear SectionWheels: Cray MantaWheel Dimensions: rear: 20x10.5; front: 19x9.0
Tires: rear: 295/35R20; front: 245/35R20Shifter: Hurst Short Shifter
Suspension: Lowered 1 inch on stock suspension
Tint: 35% Tinted
Sound: Pioneer Double Din head-unit and pioneer speakers

EngineType: 6.0L V-8 LS2
Displacement (cu in / cc): 364 / 5970
Bore & stroke (in / mm): 4 x 3.62 / 101.6 x 92
Block material: Cast Aluminum
Cylinder head material: Cast Aluminum
Valve-train: Overhead valve, 2 valves per cylinder
Fuel delivery: SFI (sequential fuel injection)
Compression ratio: 10.9:1Horsepower (hp / kW @ rpm): 400 / 298 @ 6000Torque (lb-ft / Nm @ rpm): 400 / 542 @ 4400
Recommended fuel: Premium recommended but not required
Estimated fuel economy (mpg city / hwy / combined): Manual: 18 / 28 / 22.5

Chassis / Suspension

Front: Short/long arm (SLA) double wishbone, cast aluminum upper & lower control arms, transverse-mounted composite leaf spring, monotube shock absorber
Rear: Short/long arm ( SLA ) double wishbone, cast aluminum upper & lower control arms, transverse-mounted composite leaf spring, monotube shock absorberTraction Control: Electronic traction control; Active Handling
Brakes
Type: Front and rear power-assisted disc with ABS; cross-drilled rotors with Z51 package and Magnetic Ride ControlRotor diameter x thickness (in/mm): front: 12.8x1.26 / 325x32; rear: 12x1 / 305x26

Wheels & TiresStock Wheel Size: front: 18 inch x 8.5 inch; rear: 19 inch x 10 inch
Stock Tire Size:
front: P245/40ZR18; rear: P285/35ZR19

Exterior DimensionsWheelbase (in / mm): 105.7/2685
Overall length (in / mm): 174.6 / 4435
Overall width (in / mm): 72.6 / 1844
Overall height (in / mm): 49 / 1244
Curb weight (lb / kg): 3179 / 1442

Interior DimensionsSeating capacity: 2
Interior volume (cu ft / L): 52 / 1475
Headroom (in / mm): 38 / 962
Legroom (in / mm): 43 / 1092
Shoulder room (in / mm): 55 / 1397
Hip room (in / mm): 54 / 1371

CapacitiesCargo volume (cu ft / L): 22 / 634
Fuel tank (gal / L): 18 / 68.1
Engine oil (qt / L): 5.5 / 5.2
